T0304 Characteristic
| Model | Rated Voltage(V) | Start Voltage(V) | Rated Speed (Rpm) | Rated Current(mA) | Starting Current(mA) | Armature Resistance(Ohm) | Operating Voltage(V) |
| T0304 | 2.7 | 2.7 | 14000±2500 | 75 | 90 | 33 | 2.3~3.2 |
T0304 DRAWING
Tel. : +86 577 6231 0509 E-mail : info@vibrationmotor.net
T0304 Characteristic
| Model | Rated Voltage(V) | Start Voltage(V) | Rated Speed (Rpm) | Rated Current(mA) | Starting Current(mA) | Armature Resistance(Ohm) | Operating Voltage(V) |
| T0304 | 2.7 | 2.7 | 14000±2500 | 75 | 90 | 33 | 2.3~3.2 |
T0304 DRAWING
